Klemmhalter Ø6-27mm für CC..0602.. A12-14 x1=45
Compare
| IK: | mit Kühlschmierstoff-Austritt axial |
|---|---|
| d1 (mm): | 16 |
| x3 (mm): | 23 |
Variants
| Position | Code | l1 (mm) | Passend zu | x1 (mm) | A (mm) | f (mm) | Quantity | PU | Price/PU | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 |
|
1244484 | 42 | WSP CC..0602.. | 45 | 12 - 14 | 5,8 | 1 Stück |
€117.00
|
|||
| 1 |
|
124441 | 19 | WSP WB.. 0201.. | 22 | 6 - 8 | 2,8 | 1 Stück |
€113.00
|
|||
| 2 |
|
124442 | 27 | WSP WB.. 0201.. | 30 | 8 - 10 | 3,8 | 1 Stück |
€114.00
|
|||
| 7 |
|
1244487 | 57 | WSP CC..0602.. | 60 | 16 - 18 | 7,8 | 1 Stück |
€139.00
|
|||
| 7 |
|
124447 | 57 | WSP TO.. 0802.. | 60 | 16 - 18 | 7,8 | 1 Stück |
€130.00
|
|||
| 3 |
|
124443 | 32 | WSP TO.. 0802.. | 35 | 10 - 12 | 4,8 | 1 Stück |
€118.00
|
|||
| 5 |
|
124445 | 47 | WSP TO.. 0802.. | 50 | 14 - 16 | 6,8 | 1 Stück |
€122.00
|
|||
| 5 |
|
1244485 | 47 | WSP CC..0602.. | 50 | 14 - 16 | 6,8 | 1 Stück |
€122.00
|
|||
| 3 |
|
1244483 | 32 | WSP CC..0602.. | 35 | 10 - 12 | 4,8 | 1 Stück |
€118.00
|
|||
| 9 |
|
124449 | 67 | WSP TO.. 0802.. | 70 | 25 - 27 | 12,3 | 1 Stück |
€163.00
|
|||
| 8 |
|
124448 | 67 | WSP TO.. 0802.. | 70 | 20 - 22 | 9,8 | 1 Stück |
€138.00
|
|||
| 4 |
|
124444 | 42 | WSP TO.. 0802.. | 45 | 12 - 14 | 5,8 | 1 Stück |
€117.00
|
|||
| 6 |
|
1244486 | 57 | WSP CC..0602.. | 60 | 15 - 17 | 7,4 | 1 Stück |
€130.00
|
|||
| 9 |
|
1244489 | 67 | WSP CC..0602.. | 70 | 25 - 27 | 12,3 | 1 Stück |
€163.00
|
|||
| 6 |
|
124446 | 57 | WSP TO.. 0802.. | 60 | 15 - 17 | 7,4 | 1 Stück |
€130.00
|
|||
| 8 |
|
1244488 | 67 | WSP CC..0602.. | 70 | 20 - 22 | 9,8 | 1 Stück |
€138.00
|
